Chemical Plant Engineering Design

  • Solvent Recovery Plant

  • Heat Exchanger design

  • Specialty Chemical Plant  design

  • Distillation System for petrochemical

  • Reaction System for Fine chemical

Polyacetal (POM)

POM공장 전경.jpg

  • CAS No. 24969-26-4 (Copolymer)

  • Raw Material : Formaldehyde (45~55% concentration) , and 1,3-Dioxolane

  • Product : Copolymer of Polyacetal (Polyoxymethylene/POM, Acetal Resin)

  • Typical Grade G3, G9, G27, G52

  • P&ID Company’s Manufacturing Process

Liquid reaction and production of co-polymers of Polyacetal through processing of Trioxane process (gas-liquid extraction) and polymerization process (continuous bulk polymerization) composing of the formalin concentration unit, monomer(Trioxane/TOX) unit, co-monomer unit, polymerization unit (continuous bulk polymerization), stabilization unit, formalin recovery process, and packing and storing unit.

Methyl Isobutyl Ketone (MIBK)

  • CAS No. 108-10-1

  • Raw Material : Hydrogen (98 vol%), Acetone (99.5%)

  • Product : MIBK ((CH₃)₂CHCH₂COCH₃, Min. 99.1%) and DiBK (2,6-Dimehyl-4-heptanone : By-Product)

  • P&ID Company’s Manufacturing Process

MIBK is produced from liquid acetone (Dimethyl Ketone) and gaseous hydrogen by contacting with a catalyst, strong acid cation exchange resin loaded with 0.7wt% palladium, through main system of Reaction, C6 Removal, Acetone Recovery, MIBK Separation, MIBK Concentration, DiBK Concentration.

Proposed Plant Capacity : 15,000 MTPA


Hydrogen Peroxide (H2O2)


  • CAS No. 7722-84-1

  • Raw Material : Hydrogen(99.9%), Air, Anthraquinone, Solvents, Pd catalyst

  • Product : Hydrogen peroxide (H2O2)

             Industrial grade and chemical grade of  27.5 / 35 / 50 / 60 wt%

  • P&ID Company’s Manufacturing Process

P&ID technology is one of the highly effective AO process in the world based on EAQ as the reaction carrier (working material). The major strengths and characteristics of main process step are fluidized hydrogenation, counter-current oxidation, effective extraction based on special internals, simple organic purification, safe concentration and easy regeneration without K2CO3 treatment Multiple consideration for safe operation and monitoring. No special option for procurement and raw material supply to be requested by licensor

Proposed Plant Capacity : 30,000 MTPA to 100,000 MTPA (100% Base)

Formaldehyde (Formalin)

  • CAS No. 50-00-0

  • Raw Material : Methanol

  • Product : Formaldehyde (HCHO, 37 wt%)

Formalin (Aqueous solution) : 37%, 44%, 50% inhibited (with varying percentages of methanol) or stabilized or un-stabilized (methane-free) products.

  • P&ID Company’s Manufacturing Process

Dehydrogenation and oxidation of synthetic methanol. Silver (copper, iron-molybdenum oxide) catalyst shall be introduced. High yield and selectivity, low utility consumption, and compact design and low investment cost.
Proposed Plant Capacity : 15,000 MTPY to 60,000 MTPY


Color Former (For thermal paper)


  • CAS No. 59331-94-2

  • Raw Material : m-Cresol, m-Aminophenol

  • Product : Color Former

  • P&ID Company’s Manufacturing Process

Proposed Plant Capacity : 1,000 MTPY
